Petrolio e gas In Vendita

12 ft L x 12 ft W Substructure • Stairs • Safety Rails • Schramm Drawworks • 325 kW Generator • 250 kW Generator • Schaffer/Townsend 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers***Please see the specification documents below.***

- Engine: Hyundai; Power - 420PS/2000RPM; Cooling System - Water Cooling; - Drill Head Section: Reduction - Super gear - 5.1 to 1; Max. RPM - 1st 0-150rpm; 2nd 0-200rpm; Max. Torque - 1st 2600kg-M; 2nd 1300kg-M; - Feed System Head travel 1st: 11M; 2nd: Up- 1.4M • Down- 1.8M Pull-up capacity 120ton Pull-down capacity 9ton - Main Feed Winch Spool capacity 30M of 19㎜ cable Line pull 17 tons - Sub Feed Winch Spool capacity 25M of 16㎜ cable Line pull 9 tons - Winch Spool capacity 27M of 12㎜ cable Line pull 3 tons - Main Hydraulic System 3 pump open loop system Pump discharge rate H3V280DT (P1:280cc • P2:280cc) +Gear Pump(P3:10cc) - Sub Hydraulic System 4 pump open loop system - Pump discharge rate H3V63DT (P1:63cc • P2:63cc) +HSF30D (P3:30cc • P4:30cc) - Working Table Max. Casing diameter 12" Lod Handler Tilting Degree 90° Lod Handler Clamp Size Max 127mm - Crawler Base Crawler type Solar 220 (Motor : Solar 220) Ground pressure 0.5㎏/㎠

1.7 MMBTU/hr • 6100psi • 4M Length • Coil Diameter 20 inch •

Uniflux heater with low NOx natural gas burner • heat transfercoil • seespec sheet • See Attached Spec Sheet in listing

3 in Standpipe & Manifold • Hydraulic-Explorer 2 3000 496 kW Drawworks • Marathon MagnaMax 305 kW Generator • Control Technology 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers • Foremost Pipe Arm Catwalk • Rig Moves Quickly • Small Footprint • Capable of Operating Independently Without the Need for a Third Party Coring Unit

Compressor • E-motor • Oil Separator • Gas After Filter • Oil Pumps • E-motor for Oil Pumps • Oil Cooler • Oil Filters • Seal Oil Drain Tank • Seal Oil Buffer Tanks • Piping & Valves • Junction Boxes • and Instrumentation.

Out and Down Outriggers • Rear Outriggers • detroit series 60 6 Cylinder 12.7 L Diesel 500 hp Engine • 2002 US EPA Label • Positive Air Shutoff • 14188 Engine hrs • Allison 5-Speed Automatic Transmission • Differential Lock • Aluminum Wheels • 425/65R22.5 Front Tires • 12R22.5 Rear Tires • Air Assist Front Suspension • Rubber over Walking Beam Suspension • 292 in Wheelbase • Hydraulic System • kremco 2 Drum Drawworks • LEBUS Grooved • 72 ft stiff mast • 38X10 Draw Works • BOP Class II 7 in 3K • Mast hours 4977 • BOP Tubing • Tongs and Basket for Crane

Cat C15 6 Cylinder Upper Engine • Straight Down Outriggers • Cat C15 6 Cylinder Diesel 540 hp Engine • Positive Air Shutoff • 37855 Engine hrs • Automatic Transmission • Aluminum Outer Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Walking Beam Suspension • 294 in Wheelbase • PTO • Hydraulic System • Eagle 2 Drum Drawworks

Detroit Diesel S60 Engine • Water Tank • Detroit S60 6 Cylinder Diesel Engine

4ft 11in. to 8ft 2in. • 486 tons of extracting force.

Detroit 12 Cylinder Diesel Engine • cotta Transmission • Open Top Control Station • T/A Carrier • Air Ride

Detroit 12 Cylinder Diesel Engine • Telescoping Cabin • T/A Carrier • Air Ride

Paccar PX-9 6 Cylinder 8.9 L Diesel 350 hp Engine • 2013 US EPA Label • Requires Diesel Exhaust Fluid • Positive Air Shutoff • Webasto Engine Coolant Heater • 2957.9 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Allison 3000 Automatic Transmission • Differential Lock • 6623 kg Front Axle • 10433 kg Rears • Dana S23-170 Drive Axles • 5.25:1 Axle Ratio • 17055 kg GVWR • Aluminum Wheels • 12R22.5 Front Tires • 11R22.5 Rear Tires • Hendrickson Air Ride Suspension • 238 in Wheelbase • PTO • 23 ft x 102 in Bed • Winch • Pintle Hitch • C-Tech Model X-300 Injector • Hyd Scope Bed • Rear Hyd Outriggers • Fassi Micro M30A 13 Picker • Passenger Side Hyd Extend Racks

600 HP HPU • 5 •000 psi rated system • 130 gpm plumbed to 2 of 3 rails • variable displacement Parker pumps • 1500 gal. reservoir • PLC controlled • 480V 3 phase primary power • VFD motor control • outdoor rated • skid mounted • remote oil cooler • pump and motor group can be added to third rail for future expansion.

Cat C15 15.2 L Diesel 500 hp Engine • 2005 US EPA Label • Positive Air Shutoff • 1820.5 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller 18-Speed Manual Transmission • Triple Differential Locks • Air Ride Cab • Aluminum Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Double Frame • Airliner Air Ride Suspension • 302 in Wheelbase • PTO • Dual Fuel Tanks

Spare Stamps • Manual Sample Box • Signode Strapping Machine

Cummins ISX15 6 Cylinder 15 L Diesel 525 hp Engine • 2011 US EPA Label • CARB Compliant • Requires Diesel Exhaust Fluid • Positive Air Shutoff • 5503.4 Engine hrs • Air Conditioner • Engine Brake • Eaton Fuller RTLO-18918B 18-Speed Manual Transmission • Triple Differential Locks • 19400 lb Front Axle • 60999 lb Rears • Paccar T69-170HP Drive Axles • 4.10:1 Axle Ratio • 80400 lb GVWR • Air Ride Cab • Aluminum Wheels • 445/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Double Frame • Neway Air Ride Suspension • 289 in Wheelbase • Pin Hitch

Detroit 12 Cylinder Diesel Engine • T/A Carrier • Air Ride

Multi-Fuel Fueled • 3 Phase • 480 V Input • Stamford Generator • 2013 US EPA Label • John Deere 4045TF285 4 Cylinder 74 kW 4.5 L Diesel Engine • Stamford 60 kW Generator • Tri/A Trailer • Gooseneck • Electric Brakes

Multi-Fuel Fueled • 3 Phase • 480 V Input • Stamford Generator • 2013 US EPA Label • John Deere 4045TF285 4 Cylinder 74 kW 4.5 L Diesel Engine • Stamford 60 kW Generator • Tri/A Trailer • Gooseneck • Electric Brakes

Cat C15 15.2 L Diesel 475 hp Engine • 2006 US EPA Label • 1873.7 Engine hrs • Air Conditioner • Cruise Control • Engine Brake • Eaton Fuller RTLO-18918B 18-Speed Manual Transmission • Triple Differential Locks • 16000 lb Front Axle • 51999 lb Rears • Meritor RZ-166 Drive Axles • 4.30:1 Axle Ratio • 68000 lb GVWR • Air Ride Cab • 34 in Flat Top Sleeper Cab • Aluminum Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Airliner Air Ride Suspension • 289 in Wheelbase • PTO • Dual Fuel Tanks

PTO Driven • Straight Down Outriggers • Rear Outriggers • International MaxxForce 10 12.4 L Diesel Engine • 2012 US EPA Label • Webasto Engine Coolant Heater • 7105 Engine hrs • Air Conditioner • Cruise Control • Allison 3000RDS GEN4 Automated Transmission • 14000 lb Front Axle • 40000 lb Rears • 54000 lb GVWR • Air Ride Cab • 11R24.5 • Double Frame • Spring over Walking Beam Suspension • 620 mm Wheelbase • Dual PTO • Watson Hopper 1 Drum Drawworks

6.6 m L x • ( 1 ) Crown Sheave Cluster • 80 mm Standpipe & Manifold • Deutz 96 kW Generator • 2010 Fassi Knuckle F22A22 Crane • 3 Stage Boom • A261124

Spring Suspension • 295/75R22.5 Tires • 68000 lb GVWR

Spring Suspension • 295/75R22.5 Tires • 68000 lb GVWR

Propane Fueled • 2010 US EPA Label • John Deere 6068H 6 Cylinder 6.8 L Diesel Engine

Propane Fueled • 2010 US EPA Label • John Deere 6068H 6 Cylinder 6.8 L Diesel Engine

Propane Fueled • 2010 US EPA Label • John Deere 6068HF 6 Cylinder 6.8 L Diesel Engine

Open Operator Station • 2004 US EPA Label • Deutz BF 6M 1013 C 6 Cylinder 221 hp 7.14 L Diesel Engine • 16 in Triple Grouser Track Shoes

Cat 6 Cylinder 300 hp Diesel Engine • (1) Power Unit APE 75 - (2) Auger Drives ICE-3060 •(1) Auger Drive APE 75 • 42 ft & 33 ft Leads • (11) Drill Bits • (21) Hollow Stem CFA Sections • (4) Auger Connections

2007 US EPA Label • CARB Compliant • Deutz DTC2015V08 V8 536 hp 15.8 L Diesel Engine • Containerized • Operation Manual

Detroit S60 6 Cylinder Diesel Engine

Air Ride Suspension • Air Brakes • Tail Roller • Kicker Rollers • Aluminum Outer Wheels • 275/70R22.5 Tires • 72727 kg GVWR

International DT466 7.6 L Diesel Engine • 2006 US EPA Label • 12337 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller 10-Speed Manual Transmission • 10000 lb Front Axle • 19000 lb Rears • 29000 lb GVWR • Air Ride Cab • Flat Top Sleeper Cab • Aluminum Outer Wheels • 11R22.5 Front Tires • 11R22.5 Rear Tires • Air Ride Suspension • 230 in Wheelbase • PTO

Cat 6 Cylinder Diesel Engine

2 ft 0 in L x • Four-speed transmission • Cable drill • 496 m of NQ drill rods • Water pump and pump shack • 500gal diesel fuel tank with pump.

Enclosed Cab • Air Conditioner

Rear Outriggers • Hydraulic Hose Reel • International HT570 6 Cylinder 9.3 L Diesel Engine • Positive Air Shutoff • Webasto Engine Coolant Heater • 14008 Engine hrs • Air Conditioner • Cruise Control • Engine Brake • Eaton Fuller 13-Speed Manual Transmission • Differential Lock • Air Ride Cab • Aluminum Wheels • 11R22.5 • Air Ride Suspension • 262 in Wheelbase • PTO • 800 m 1/2 In 5x7 Braided Line • 1 to 1 Right Angle Drive Switched From 8 In To 10 In • 10000 Ft Drum Capacity • C/W Spare 7 Series Transfer Case • Innovative Digital Counter System • Dual Magnet • Depth • Weight • Meter Per Minute • Double 120 Chain • Engine Rebuilt At 191985 Km

Cummins 6 Cylinder 6.8 L 400 hp Engine • US EPA Label • 3137 Engine hrs • Engine Brake • Manual Transmission • 385/65R22.5 Front Tires • 11R24.5 Rear Tires • Walking Beam Suspension • 380 in Wheelbase • PTO • 26 ft 7 in x 108 in Bed • Tail Roll • 21 ft Double Frame Gin Poles • Broken Arrow Winch • Flip-Over 5th-Wheel • Cummins Big Cam 400 hp • 6 spd • 4 spd aux • beam susp • 22000 lb ft • 46000 lb rear • 380 in WB • 26ft x 8 ft 6 in bed • live roll • 20 ft dbl frame gin poles • Braden 50 ton winch • flip-over 5th wheel

Detroit DD15 6 Cylinder 14.8 L Diesel 475 hp Engine • 14470.5 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller RTLO-18918B 18-Speed Manual Transmission • 2-Speed Auxiliary Transmission • 40000 lb Front Axle • 64000 lb Rears • Meritor RT-70-380P Drive Axles • 5.52:1 Axle Ratio • 100000 lb GVWR • Air Ride Cab • Aluminum Front Wheels • 425/65R22.5 Front Tires • 12.00R24 Rear Tires • Dual Steering Boxes • Walking Beam Suspension • 398 in Wheelbase • PTO • 29 ft x 109 in Bed • Tail Roll • 32 ft Gin Poles • Tulsa RN130 130000 lb Winch • Tulsa RN120 120000 lb Winch • 3rd winch

Cummins ISX 6 Cylinder 15.0 L Diesel 450 hp Engine • 2007 US EPA Label • 3391.3 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller FRO-15210C 10-Speed Manual Transmission • Spicer 4-Speed Auxiliary Transmission • 21500 lb Front Axle • 61500 lb Rears • 83000 lb GVWR • Aluminum Front Wheels • 445/65R22.5 Front Tires • 12.00R24 Rear Tires • Dual Steering Boxes • Walking Beam Suspension • 402 in Wheelbase • PTO • 28 ft x 102 in Bed • Tail Roll • Tulsa RN100 100000 lb Winch

32 ft Minimum Boom Length • 640 lb 25 ton Capacity McKissick 2 Sheave Hook Block • Cabin/Control Cosole/Power Pack
